| Выноска |
Номер детали |
Название детали |
Примечания |
Кол-во |
| 1 |
68003-51K00 |
PANEL ASSY, REAR DOOR RH |
|
1 |
| 2 |
68004-51K00 |
PANEL ASSY, REAR DOOR LH |
|
1 |
| 3 |
69410-63JA0 |
HINGE, DOOR UPPER RH |
|
1 |
| 4 |
69420-63JA0 |
HINGE, DOOR UPPER LH |
|
1 |
| 5 |
69430-63JA0 |
HINGE, DOOR LOWER RH |
|
1 |
| 6 |
69440-63JA0 |
HINGE, DOOR LOWER LH |
|
1 |
| 7 |
08361-2508A |
NUT |
|
4 |
| 8 |
09159-08132 |
NUT |
|
4 |
| 9 |
09103-08389 |
BOLT (8X24) |
|
8 |
| 10 |
81830-51K02 |
STOP, REAR DOOR OPEN |
|
2 |
| 11 |
09112-08015 |
BOLT (8X25) |
|
2 |
| 12 |
09122-86004 |
SCREW (6X20) |
|
4 |
| 13 |
82711-65J00 |
STOPPER, DOOR |
|
4 |
| 14 |
83730-51K00-EWS |
TRIM, DOOR RH (GRAY) |
GA |
1 |
| 14 |
83730-51K00-DEZ |
TRIM, DOOR RH (GRAY/BLACK) |
GA,GL,GLS,GLS:66KW, GLSECO |
1 |
| 15 |
83717-79J00 |
.CLIP |
|
6 |
| 16 |
09409-10312 |
.CLIP |
|
2 |
| 17 |
83740-51K00-EWS |
TRIM, DOOR LH (GRAY) |
GA |
1 |
| 17 |
83740-51K00-DEZ |
TRIM, DOOR LH (GRAY/BLACK) |
GA,GL,GLS,GLS:66KW, GLSECO |
1 |
| 18 |
83717-79J00 |
.CLIP |
|
6 |
| 19 |
09409-10312 |
.CLIP |
|
2 |
| 20 |
09409-06314-S1S |
CLIP (GRAY) |
|
4 |
| 21 |
83871-51K00 |
WEATHERSTRIP, DOOR INNNER RH |
|
1 |
| 22 |
83881-51K00 |
WEATHERSTRIP, DOOR INNNER LH |
|
1 |
| 23 |
83913-51K00 |
COVER, DOOR SEALING |
|
2 |
| 24 |
83751-75HA0 |
BRACKET, DOOR TRIM RH |
|
1 |
| 25 |
83756-75HA0 |
BRACKET, DOOR TRIM LH |
|
1 |
| 26 |
09132-05058 |
SCREW (5X12) |
|
2 |
| 27 |
09148-06007 |
NUT |
|
2 |
| 28 |
03241-0612A |
SCREW |
|
2 |
| 29 |
83717-51K00 |
PAD, DOOR TRIM REGULATOR |
|
2 |
| 30 |
84661-51K00 |
WEATHERSTRIP, DOOR OPENING RH |
|
1 |
| 31 |
84671-51K00 |
WEATHERSTRIP, DOOR OPENING LH |
|
1 |
| 32 |
83931-51K00-0CB |
TAPE, DOOR OUTER RH (BLACK) |
GLS,GLS:66KW, GLSECO |
1 |
| 33 |
83932-51K00-0CB |
TAPE, DOOR OUTER LH (BLACK) |
GLS,GLS:66KW, GLSECO |
1 |
