| Выноска |
Номер детали |
Название детали |
Примечания |
Кол-во |
| 1 |
69100-85L20 |
PANEL ASSY, BACK DOOR |
GLS,GLSECO |
1 |
| 2 |
69510-51K00 |
HINGE, BACK DOOR |
|
2 |
| 3 |
69571-76G00 |
.PACKING, HINGE FEMALE |
|
2 |
| 4 |
09111-06086 |
BOLT (6X12) |
|
4 |
| 5 |
08361-2508A |
NUT |
|
2 |
| 6 |
81850-51811 |
BALANCER, BACK DOOR RH |
|
1 |
| 7 |
81860-51811 |
BALANCER, BACK DOOR LH |
|
1 |
| 8 |
09113-08002 |
BOLT (8X12) |
|
4 |
| 9 |
82683-80E20 |
CUSHION, BACK DOOR SIDE |
|
2 |
| 10 |
83940-85L00-ZCC |
GARNISH, DOOR HANDLE (SILVER) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZCD |
GARNISH, DOOR HANDLE (GRAY) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZCE |
GARNISH, DOOR HANDLE (BLACK) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZCF |
GARNISH, DOOR HANDLE (RED) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZCG |
GARNISH, DOOR HANDLE (BLUE) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZFS |
GARNISH, DOOR HANDLE (COPPER) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZKC |
GARNISH, DOOR HANDLE (TURQUOISE) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZNL |
GARNISH, DOOR HANDLE (WHITE) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZRM |
GARNISH, DOOR HANDLE (GREEN) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-26U |
GARNISH, DOOR HANDLE (WHITE) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZDQ |
GARNISH, DOOR HANDLE (BLUE) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZUC |
GARNISH, DOOR HANDLE (BROWN) |
GLS,GLSECO |
1 |
| 10 |
83940-85L00-ZUM |
GARNISH, DOOR HANDLE (BLUE) |
GLS,GLSECO |
1 |
| 11 |
71812-78F00 |
.CLIP |
|
5 |
| 12 |
83942-51K10 |
.BOLT |
|
4 |
| 13 |
83945-85L00 |
.BRACKET, BACK DOOR |
|
1 |
| 14 |
03541-0416A |
.SCREW |
|
2 |
| 15 |
08316-1006A |
NUT |
|
4 |
| 16 |
83770-51K00-S1S |
TRIM, BACK DOOR (GRAY) |
|
1 |
| 17 |
09409-10312 |
.CLIP |
|
9 |
| 18 |
09409-08331 |
.CLIP |
|
2 |
| 19 |
09409-07308-S1S |
CLIP (GRAY) |
|
1 |
| 20 |
82850-80M00 |
HANDLE ASSY, BACK DOOR LOCK |
TYPE 4 |
1 |
| 21 |
08316-1006A |
NUT |
|
2 |
| 22 |
84515-65D00 |
FEMALE, GLASS FASTENER |
|
4 |
| 23 |
09250-20023 |
CAP (OD:25.8) |
|
1 |
| 24 |
84570-51K00 |
GLASS, BACK WINDOW (GREEN) |
|
1 |
| 24 |
84570-51K10 |
GLASS, BACK WINDOW (DARK GREEN) |
|
1 |
| 25 |
84513-76F00 |
.MALE, GLASS FASTENER NO.2 |
|
2 |
| 26 |
84572-74G00 |
.MALE, GLASS FASTENER NO.1 |
|
2 |
| 27 |
84623-51K00 |
.MOLDING, BACK DOOR WINDOW RH |
|
1 |
| 28 |
84624-51K00 |
.MOLDING, BACK DOOR WINDOW LH |
|
1 |
| 29 |
63191-25C00 |
PAD |
|
2 |
| 30 |
77151-82000 |
SEAL |
|
2 |
| 31 |
83910-51K00 |
DRIP, BACK DOOR SIDE RH |
|
1 |
| 32 |
83920-51K00 |
DRIP, BACK DOOR SIDE LH |
|
1 |
| 33 |
84681-51K00 |
WEATHERSTRIP, DOOR OPENING |
|
1 |
