| Выноска |
Номер детали |
Название детали |
Примечания |
Кол-во |
| 1 |
35650-64J10 |
LAMP UNIT, RR COMBINATION RH |
E02 |
1 |
| 1 |
35650-64J20 |
LAMP UNIT, RR COMBINATION RH |
E09,E10,E22,E24,E30,E43, E50,E54,E85,E96 |
1 |
| 2 |
35670-64J20 |
LAMP UNIT, RR COMBINATION LH |
E02,E09,E10,E24,E30,E43, E85,E96 |
1 |
| 2 |
35670-64J10 |
LAMP UNIT, RR COMBINATION LH |
E22,E50,E54 |
1 |
| 3 |
35658-64J10 |
SOCKET & CORD ASSY (W/REAR FOG LAMP) |
E02:RH E22,E50,E54:LH |
1 |
| 4 |
35658-64J20 |
SOCKET & CORD ASSY (W/BACK UP LAMP) |
E09,E10,E24,E43,E96 |
2 |
| 4 |
35658-64J20 |
SOCKET & CORD ASSY (W/BACK UP LAMP) |
E02:LH E22,E50,E54:RH |
1 |
| 5 |
09471-12083 |
BULB (12V,21/5W) |
|
2 |
| 6 |
09471-12186 |
BULB (12V,21W) (AMBER) |
|
2 |
| 7 |
09471-12146 |
BULB (12V,18W) (W16W) |
|
2 |
| 8 |
09471-12045 |
BULB (12V,21W) |
W/REAR FOG LAMP |
1 |
| 9 |
35153-65J00 |
GROMMET, REAR COMBINATION LAMP |
|
4 |
| 10 |
02162-0616C |
BOLT |
|
4 |
| 11 |
71812-78F00 |
CLIP |
|
2 |
| 12 |
35810-65J00 |
LAMP ASSY, HIGH MOUNT STOP |
|
1 |
| 13 |
36218-74F00 |
.SOCKET |
|
4 |
| 14 |
09471-12216 |
.BULB (12V,5W) |
|
4 |
| 15 |
35910-75F21 |
LAMP ASSY, LICENSE |
|
2 |
| 16 |
09471-12081 |
.BULB (12V,5W) |
|
2 |
| 17 |
35970-07F01 |
REFLECTOR ASSY, REAR |
|
2 |
| 18 |
08316-1005A |
NUT |
|
2 |
| 19 |
36210-63J01-6GS |
LAMP ASSY, ROOM (GRAY) |
|
1 |
| 20 |
36212-63J00 |
.LENS |
|
1 |
| 21 |
09471-12181 |
.BULB (12V,10W) |
|
1 |
| 22 |
36210-54G20 |
LAMP ASSY, LUGGAGE ROOM |
|
1 |
| 23 |
09471-12081 |
.BULB (12V,5W) |
|
1 |
| 24 |
36632-64J00 |
WIRE, LUGGAGE ROOM LAMP |
|
1 |
| 25 |
36216-65J00 |
COVER, DOOR ILLUMINATION LAMP HOLE |
TYPE 1 |
2 |
