| Выноска |
Номер детали |
Название детали |
Примечания |
Кол-во |
| 1 |
37210-64J10 |
SWITCH ASSY, LIGHTING & TURN |
E09,E10,E43,E96 |
1 |
| 1 |
37210-58J20 |
SWITCH ASSY, LIGHTING & TURN |
E22,E50,E54 |
1 |
| 2 |
37310-62J30 |
SWITCH ASSY, WIPER & WASHER |
|
1 |
| 3 |
37480-73H00 |
CABLE ASSY, CONTACT COIL |
N/STEERING AUDIO SWITCH |
1 |
| 3 |
37480-62J00 |
CABLE ASSY, CONTACT COIL |
W/STEERING AUDIO SWITCH |
1 |
| 4 |
35180-62J00 |
SWITCH ASSY, HEADLAMP LEVELING |
W/HEADLAMP LEVELING |
1 |
| 5 |
37270-62J00 |
SWITCH ASSY, FRONT FOG LAMP |
W/FRONT FOG LAMP |
1 |
| 6 |
39650-62J00 |
SWITCH ASSY, ILLUMINATION CANCEL |
E22,E54 |
1 |
| 7 |
37285-62J00 |
CAP, OPTION SWITCH HOLE |
|
AR |
| 8 |
37430-64J00-5PK |
SWITCH ASSY, HAZARD WARNING (BLACK) |
|
1 |
| 9 |
37740-75H10 |
SWITCH ASSY, STOP LAMP |
|
1 |
| 10 |
37670-58J10 |
SWITCH ASSY, DOOR |
|
2 |
| 11 |
37670-79A10 |
SWITCH ASSY, BACK DOOR |
|
1 |
| 12 |
37285-50J01 |
CAP, OPTION SWITCH HOLE |
N/SEAT HEATER |
2 |
| 13 |
37850-64J00 |
SWITCH ASSY, SEAT HEATER |
W/SEAT HEATER |
2 |
| 14 |
37990-64J60 |
SWITCH ASSY, POWER WINDOW MAIN |
E09,E10,E43,E50,E96 |
1 |
| 14 |
37990-62J10 |
SWITCH ASSY, POWER WINDOW MAIN |
E22,E54 |
1 |
| 15 |
37995-62J00 |
SWITCH ASSY, POWER WINDOW SUB |
|
1 |
| 16 |
37950-62J00 |
SWITCH ASSY, MIRROR |
|
1 |
| 17 |
38500-63J00 |
HORN ASSY, LOW PITCHED |
E09,E10,E22,E50,E54,E96 |
1 |
| 17 |
38500-65J20 |
HORN ASSY, LOW PITCHED |
E43 |
1 |
| 18 |
38500-65J10 |
HORN ASSY, HIGH PITCHED |
E09,E10,E22,E50,E54,E96 |
1 |
| 18 |
38500-65J31 |
HORN ASSY, HIGH PITCHED |
E43 |
1 |
| 19 |
09115-08001 |
BOLT (8X16) |
|
2 |
| 20 |
38610-84F21 |
RELAY ASSY, TURNSIGNAL |
|
1 |
| 21 |
36770-64J71 |
CONTROLLER ASSY, BODY ELECTRIC |
E09,E10,E96 |
1 |
| 21 |
36770-64JE1 |
CONTROLLER ASSY, BODY ELECTRIC |
JB416X:E22 |
1 |
| 21 |
36770-64JB1 |
CONTROLLER ASSY, BODY ELECTRIC |
JB419XD:E22 |
1 |
| 21 |
36770-64J91 |
CONTROLLER ASSY, BODY ELECTRIC |
E43 |
1 |
| 21 |
36770-64JA0 |
CONTROLLER ASSY, BODY ELECTRIC |
E50 |
1 |
| 21 |
36770-64JE1 |
CONTROLLER ASSY, BODY ELECTRIC |
E54 |
1 |
| 22 |
02162-0616C |
BOLT |
|
2 |
| 23 |
37190-64J20 |
RECEIVER ASSY, KEYLESS ENTRY |
E09,E10,E50,E96 W/KEYLESS ENTRY |
1 |
| 23 |
37190-64J10 |
RECEIVER ASSY, KEYLESS ENTRY |
E22,E43,E54 W/KEYLESS ENTRY |
1 |
| 24 |
03141-0516A |
SCREW |
|
1 |
| 25 |
39400-65J01 |
LIGHTER ASSY, CIGARETTE |
W/CIGAR LIGHTER |
1 |
| 26 |
39410-60A01 |
SOCKET ASSY |
|
1 |
| 27 |
39410-64J00-5PK |
SOCKET ASSY (BLACK) |
|
1 |
| 28 |
34600-65J01 |
MONITOR ASSY, INFORMATION |
E09,E10,E43,E50,E96 |
1 |
| 28 |
34600-65J21 |
MONITOR ASSY, INFORMATION |
E22,E54 |
1 |
| 29 |
09409-08326 |
.CLIP |
|
3 |
| 30 |
95643-58J00 |
SENSOR, OUTSIDE TEMPERATURE |
|
1 |
| 31 |
38910-65J40 |
CONTROLLER ASSY, AIR BAG |
W/2AB |
1 |
| 31 |
38910-65J50 |
CONTROLLER ASSY, AIR BAG |
W/6AB |
1 |
| 32 |
09115-06003 |
BOLT (6X16) |
|
3 |
| 33 |
38930-65J00 |
SENSOR ASSY, FORWARD RH |
|
1 |
| 34 |
38930-65J10 |
SENSOR ASSY, FORWARD LH |
|
1 |
| 35 |
02162-0612A |
SCREW |
|
4 |
| 36 |
36550-59J00 |
LAMP ASSY, ILLUMINATION |
|
1 |
| 37 |
09471-12055 |
.BULB (12V,1.4W T5) |
|
1 |
| 38 |
38930-65J30 |
SENSOR ASSY, SIDE AIR BAG |
W/6AB |
1 |
| 39 |
02162-06353 |
BOLT |
W/6AB |
4 |
